MFI_AE

This model is Basic model and used to measure MFI value of Polymers as per Method A, this is having manual process to cut the sample on specific interval of time on buzzer indication with Knife. Then we have to weigh the sample and can calculate MFI value Manually.

MFI_AC

This model is Semi-Automatic model and used to measure MFI value of Polymers as per Method A, this is having Motorized process to cut the sample on specific interval of time as per set value of Time. Then we have to weigh the sample and can calculate MFI value Manually.

MFI_AFA

This model is Automatic model and used to measure MFI value of Polymers as per Method A, this is having Motorized process to cut the sample on specific interval of time as per set value of Time. It also have balance to weigh the extruded sample on pan and programmed Microcontroller will calculate MFI value with each cut and also calculate Average weight of sample & MFI value. It is having compute software and connected with PC to operate with software and save the reports in PC.

MFI_S2200

This model is Fully Automatic model and used to measure MFI value of Polymers as per Method A, B, C and MVR as per Method B. It can calculate Intrinsic Viscosity (IV) for PET. Calculate Melt Density at specific interval of time. This is having Touch HMI and PLC controlled operation. Motorized process to cut the sample on specific interval of time as per set value of Time. It also has encoders to measure the travel of Piston. Auto Loading of weights as per set Load can be applied. It is having computer software and connected with PC to operate with software and save the reports in PC.

Melt Flow Index Tester (MFI) Overview

Saumya's MFI (Melt Flow Index Tester) is used to determine the flow properties of thermoplastic materials by measuring the rate at which molten polymer flows through a standard die under specified temperature and load conditions. The result, known as the Melt Flow Index (MFI) or Melt Flow Rate (MFR), provides a direct indication of the material’s viscosity and processing behavior.

Our Melt Flow Indexer is designed for accurate and reliable testing of polymers such as PE, PP, PVC, ABS, and other thermoplastics. The instrument operates by heating the sample to a predefined temperature and applying a constant load, allowing the molten material to extrude through a standard die over a specified period.

The system is equipped with precise temperature control, automatic timing, and advanced measurement mechanisms to ensure highly repeatable and consistent results. It is widely used for quality control, material comparison, and process optimization in plastic manufacturing industries.

To meet diverse testing requirements, Saumya’s Melt Flow Indexer is available in multiple models, including MFI-AE, MFI-AC, MFI-AFA, and MFI-S2200, each designed to cater to different levels of automation, accuracy, and testing convenience.

Application

Used to determine the Melt Flow Rate (MFR) of thermoplastic polymers under controlled temperature and load conditions.
Suitable for testing different polymer materials such as PVC, HDPE, LDPE, PP, ABS, PET, and other thermoplastics.
Widely used in plastic manufacturing industries to distinguish between different grades of polymer materials.
Applied in quality control laboratories to ensure consistency of raw materials and finished plastic products.
Used in research and development laboratories for evaluating processing characteristics of new polymer formulations.
Helps in analyzing flow properties and viscosity behavior of molten plastic materials.
Useful for monitoring batch-to-batch consistency during polymer production.
Suitable for plastic pipe, film, injection molding, and extrusion industries to verify material processing performance.

USP

High precision temperature control system ensuring accurate melt flow measurement.
Microprocessor / PLC based control for reliable and repeatable test results.
Designed to perform tests as per various national and international standards.
Robust and compact construction ensuring stable and long-term operation.
Motorized cutting mechanism for consistent sample cutting at preset intervals.
Optional fully automatic models with integrated weighing system for direct MFI calculation.
User-friendly interface with digital display or touch screen HMI for easy operation.
PC connectivity and software support for data logging and report generation.
Capability to measure MFI, MFR, MVR and melt density in advanced models.
Low maintenance design suitable for continuous laboratory and industrial use.

Model Specifications

Features	MFI-AE	MFI-AC	MFI-AFA	MFI-S2200
Temperature Range	0-400 °C	0-400 °C	0-400 °C	0-400 °C
Control	PID Control	PID Control	PID Control	PID Control
Microprocessor Timer	0-999.9 sec	0-999.9 sec	0-999.9 sec	99999.9 sec
Accuracy	±0.1 °C	±0.1 °C	±0.1 °C	±0.1 °C
Weighing Scale	-	-	0-300 g	-
Sample Cutting	Manual	Auto	Auto	Auto
Interface	-	-	RS-232	USB
Displacement Measurement	-	-	-	Digital Sensor
Method of Test	A	A	A	A,B,C
Body	MS with Powder Coating / S.S. Body
Power Supply	1 Phase, 50/60 Hz
Dimensions (Inches)	20 × 17 × 24	20 × 17 × 24	18 × 17 × 30	18 × 17 × 45
Net Weight	45 Kg	46 Kg	50 Kg	60 Kg

Test Standards

TS EN ISO 1133 DIN 53775 ASTM D1238 ASTM D3364 TS 11451 TS 418 EN 12201 TS EN ISO 15874 TS EN 253 IS 4984
